The surface accuracy of the flange sealing surface contacted by spiral wound gasket is not high. Spiral wound gasket is especially suitable for the occasion of uneven load, easy relaxation of joint force, periodic change of temperature and pressure, impact or vibration. Spiral wound gasket is an ideal static sealing element for flange joints of. These are Quick to install and remove. Gasket are made in a wide variety of sizes and shapes. Support rings, inside and Outside the spiral, improve the gasket’s handing, fitting and Versatility. Construction of Spiral Wound Gasket. For proper positioning, spiral wound gaskets are provided with outer centering ring made up of Carbon Steel. These are Quick to install and remove. Gasket are made in a wide variety of sizes and shapes. Support rings, inside and Outside the spiral, improve the gasket’s handing, fitting and Versatility. Construction of Spiral Wound Gasket. For proper positioning, spiral wound gaskets are provided with outer centering ring made up of Carbon Steel. Graphite or Spiral Wound 6 1/2 60. Spiral Wound Gaskets. Proper gasket installation. All applicable safety standards including lockout/tagout procedures should be observed. Spiral wound gaskets require a much higher minimum seating stress where the torque values used for cut gaskets. The installation method of the PTFE gasket is different depending on the type of the machine and the type of the machine, but the installation methods are the same. The steps and precautions for installing the PTFE gasket are as follows: 1. Before the PTFE gasket is installed, the shaft (shaft sleeve) and the gland have no burrs. After about 5 years, the industry moved to make spiral wound gaskets the standard in ASME B16.20. An amendment to ASME B16.20 in May 2008 made the use of inner rings within spiral wound gaskets standard. The standard states: “ Inner rings shall be furnished with all spiral-wound gaskets having PTFE (polytetrafluoroethylene) filler material.

The spiral wound gasket can be used to seal fluid pressures up to 250 bar and cryogenic temperatures as low -200 and up to elevated temperatures 550. Due to its sturdy design the spiral wound gasket is simple to install without causing damage (although extra care should be taken during transportation and installation of large diameter gasket.

Next:

Equipment - Clean and Examine - Align Flanges - Install Gasket - Lubricate Load Bearing Surfaces - Tighten -

The Fluid Sealing Association, (FSA), in conjunction with the European Sealing Association, (ESA), have created a Gasket Installation Procedures pocket book (available in nine languages on the FSA and ESA websites, fluidsealing.com, europeansealing.com) to help installers focus on the key points of proper gasket installation. Following is a summary of the six principal areas of focus in sequential order.Prior to starting any installation, it is important to follow all company safety procedures and policies to ensure the system has been depressurized, drained and de-energized (lockout and tagout procedures) and have all the necessary personal protection equipment (PPE) and tools to help the job go as smoothly and as safely as possible.

At minimum, equipment should consist of:

• calibrated torque wrench or other tightening device

• wire brush

• hard hat

• safety goggles and/or face shield

• lubricant

• other plant specified equipment

Step 1: Clean and Examine

Once the gasket has been removed from the flange, remove any foreign materialor gasket debris from the sealing surface. Using a wire brush, physically remove any material embedded in the sealing face or flange serrations. Be careful not to use a grinder, hammer and chisel, or abrasive material that could further damage the flange sealing surface. Inspect the sealing face for dents, dings, mars or pitting that could cause sealing issues. If there is any noticeable flange face damage, youcan refer to ASME PCC-1 Appendix D—guidelines for allowable gasket contact surface flatness and defect depth, to determine if repairs to the flange are required. Inspect fasteners such as bolts, washers and nuts for defects, cracks and burrs. If fastener components are determined to be defective then discard and replace.Examination Tip: When inspecting bolts and nuts, make sure that nuts run freely over the threads prior to installation to ensure there is no damage to the threads.

Step 2. Align Flanges

To create an effective seal, the installer must ensure that the flanges are parallel as they are brought together. This gives the best chance of applying a uniform maximum gasket load, creating the best seal. ASME PCC-1-2013 Appendix E—Flange Joint Guidelines, gives the recommended allowable limits for:

• flange parallelism

• centerline high/low (the alignment of inner diameter (ID) of the flangebore or outer diameter (OD) of the flange meet)

• rotational-two hole (rotational alignment of bolt holes to allowthe insertion of fasteners without inding)

• excessive spacing, which is defined as when the distance between the two flanges is more than twice of the gasket thickness selected If the system piping requires more than normal force to bring the two flanges together, contact or consult with an engineer. Do not try and over tighten the bolts in hopes of bringing the flanges together.

Alignment Tip:

Avoid using a pry bar or screwdriver to align flanges. Proper tools are available to help with both linear and rotational alignment that are safer and easier to use.

Step 3. Install Gasket

Before installing, inspect the gasket to ensure that it is free of defects and that it was cut cleanly with no rips or tears.

Carefully insert the gasket between the flanges, making sure it is centered between the flanges. In the case of difficult or horizontal installations, never apply release agents or joint compounds on the sealing surface of the gasket. Doing this causes two main problems:

1. The joint is now lubricated making it easier for the gasket to extrude from the flange as a result of internal pressure and hydrostatic end forces that are acting upon the joint.

2. The material can cause a chemical attack on the gasket, compromising the gasket properties and its service life expectancy.

Installation Tip:

For full face gaskets, inserting two to three bolts through both flanges and gasket will help locate the gasket and keep it from moving while bringing the flanges together, reducing the risk of pinching or damaging the gasket.

Step 4. Lubricate Load Bearing Surfaces

Lubrication or anti-seize is a critical step in any gasket installation. It helps with the assembly and in the case of anti-seize, also helps with the disassembly. It is important to consider factors such as temperature, particle type and size when selecting the proper lubrication or anti-seize paste. Without using a high-quality lubricant/anti-seize with a consistent K factor, tightening the bolt to the manufacturer’s recommended torque value will not actually transmit the tensile forces that are required. The application of lubricant is important, and the installer must ensure it is applied uniformly to all thread, nut and

washer load-bearing surfaces. The installer should also ensure that they do not apply lubricant or anti-seize to either the gasket or the sealing surface. Refer to Step 3 for more information.

Lubrication Tip:

/novell-client-windows-10-download.html. Not sure how much lubrication is enough? If you can’t see it applied on the fasteners from less than five feet away, then it’s probably not enough.

Step 5. Install & Tighten Bolts

Before tightening the nuts, consult the gasket manufacturer for recommended torque values. It is important to ensure that bolt stresses created by the recommended torque are within the allowable limits for the bolting material. Otherwise a failure can occur. When tightening the nut, it is important that the installer try to bring the flanges together in parallel as much as possible.

The best way to achieve this is to always tighten nuts using the legacy method or cross bolt pattern and by using multiple (three to four) tightening rounds during installation. During the tightening rounds, using a gap measurement tool or Vernier calipers to measure the spacing between the flanges is good way to ensure the flanges are parallel during the tightening process. In cases where the gap measurements are not similar, it may be necessary to reduce the bolt torque or untighten a nut in the appropriate location until the flange gap measurement is uniform.

To Tighten:

• Tighten all nuts by hand but do not exceed 20 percent of the recommended torque.

• Round 1: Torque each nut to approximately 30 percent of the recommended torque.

• Round 2: Torque each nut to approximately 60 percent of full torque.

• Round 3: Torque each nut to approximately 100 percent of the full torque.

• Round 4: Apply at least one final full torque to all nuts in a clockwise position until all nuts are a uniform torque.

Tightening Tip:

It is a good idea to number the bolts in the order of tightening, so that you can easily

follow them for multiple tightening rounds. This is especially important for large diameter flanges that have a lot of bolts. It has been well documented that relaxation in a bolted joint flange assembly occurs within the first four to 24 hours after initial installation due to gasket creep, and bolt and flange relaxation. It is strongly recommended that users retorque within this four to 24 hour window, while the system is still at ambient temperature and atmospheric pressure, before being put back online. In some cases, this simply cannot be done and the system is to be put back online for service immediately after the gasket is reinstalled. In this case, using the maximum allowable torque is recommended to help combat some of the joint relaxation.

Spiral Wound Gasket Installation Procedure To Install Valve

At no time is it recommended that an elastomer-based soft gasket material be retorqued after the material has been exposed to elevated temperatures (known as hot torqueing). Doing this with an elastomer-based material can cause the gasket to crack, possibly causing a blowout and severe injuries.

Spiral Wound Gasket Types

Retightening Tip:

When retightening within the appropriate time frame of four to 24 hours, start at Round 3 noted in Step 5 and torque each nut to approximately 100 percent of the full torque, followed by a rotational round at the final full torque to ensure all nuts are a uniform torque. Doing all of this cannot guarantee that your gasket will not leak, but if you focus on these six main areas, the bolted joint flanged assembly has the best chance of creating an effective and reliable seal. These procedures are for standard flanges. There is some specialty equipment that may require special steps. In all cases, adhere strictly to safety procedures.

(Source: Chett Norton C.E.T. Member of the FSA Technical Gasket Committee 06/2017)
